Insert Image in SQLite and Display in ListView

Hello friends now i am telling you how to insert image in sqlite and display in listview. Its my hard work to find the code because many of site have display image in listview but they fetch the images from drawable folder which not need of myself and you too.



DataBaseHandler.java

package com.example.sqliteimagedemo;
import java.util.ArrayList;
import java.util.List;

import android.content.ContentValues;
import android.content.Context;
import android.database.Cursor;
import android.database.sqlite.SQLiteDatabase;
import android.database.sqlite.SQLiteOpenHelper;

public class DataBaseHandler extends SQLiteOpenHelper {

// All Static variables
// Database Version
private static final int DATABASE_VERSION = 1;

// Database Name
private static final String DATABASE_NAME = "imagedb";

// Contacts table name
private static final String TABLE_CONTACTS = "contacts";

// Contacts Table Columns names
private static final String KEY_ID = "id";
private static final String KEY_NAME = "name";
private static final String KEY_IMAGE = "image";

public DataBaseHandler(Context context) {
super(context, DATABASE_NAME, null, DATABASE_VERSION);
}

// Creating Tables
@Override
public void onCreate(SQLiteDatabase db) {
String CREATE_CONTACTS_TABLE = "CREATE TABLE " + TABLE_CONTACTS + "("
+ KEY_ID + " INTEGER PRIMARY KEY," + KEY_NAME + " TEXT,"
+ KEY_IMAGE + " BLOB" + ")";
db.execSQL(CREATE_CONTACTS_TABLE);
}

// Upgrading database
@Override
public void onUpgrade(SQLiteDatabase db, int oldVersion, int newVersion) {
// Drop older table if existed
db.execSQL("DROP TABLE IF EXISTS " + TABLE_CONTACTS);

// Create tables again
onCreate(db);
}

/**
* All CRUD(Create, Read, Update, Delete) Operations
*/

public// Adding new contact
void addContact(Contact contact) {
SQLiteDatabase db = this.getWritableDatabase();

ContentValues values = new ContentValues();
values.put(KEY_NAME, contact._name); // Contact Name
values.put(KEY_IMAGE, contact._image); // Contact Phone

// Inserting Row
db.insert(TABLE_CONTACTS, null, values);
db.close(); // Closing database connection
}

// Getting single contact
Contact getContact(int id) {
SQLiteDatabase db = this.getReadableDatabase();

Cursor cursor = db.query(TABLE_CONTACTS, new String[] { KEY_ID,
KEY_NAME, KEY_IMAGE }, KEY_ID + "=?",
new String[] { String.valueOf(id) }, null, null, null, null);
if (cursor != null)
cursor.moveToFirst();

Contact contact = new Contact(Integer.parseInt(cursor.getString(0)),
cursor.getString(1), cursor.getBlob(1));

// return contact
return contact;

}

// Getting All Contacts
public List<Contact> getAllContacts() {
List<Contact> contactList = new ArrayList<Contact>();
// Select All Query
String selectQuery = "SELECT * FROM contacts ORDER BY name";

SQLiteDatabase db = this.getWritableDatabase();
Cursor cursor = db.rawQuery(selectQuery, null);
// looping through all rows and adding to list
if (cursor.moveToFirst()) {
do {
Contact contact = new Contact();
contact.setID(Integer.parseInt(cursor.getString(0)));
contact.setName(cursor.getString(1));
contact.setImage(cursor.getBlob(2));
// Adding contact to list
contactList.add(contact);
} while (cursor.moveToNext());
}
// close inserting data from database
db.close();
// return contact list
return contactList;

}

// Updating single contact
public int updateContact(Contact contact) {
SQLiteDatabase db = this.getWritableDatabase();

ContentValues values = new ContentValues();
values.put(KEY_NAME, contact.getName());
values.put(KEY_IMAGE, contact.getImage());

// updating row
return db.update(TABLE_CONTACTS, values, KEY_ID + " = ?",
new String[] { String.valueOf(contact.getID()) });

}

// Deleting single contact
public void deleteContact(Contact contact) {
SQLiteDatabase db = this.getWritableDatabase();
db.delete(TABLE_CONTACTS, KEY_ID + " = ?",
new String[] { String.valueOf(contact.getID()) });
db.close();
}

// Getting contacts Count
public int getContactsCount() {
String countQuery = "SELECT * FROM " + TABLE_CONTACTS;
SQLiteDatabase db = this.getReadableDatabase();
Cursor cursor = db.rawQuery(countQuery, null);
cursor.close();

// return count
return cursor.getCount();
}
}


Download ImageSQLite Project

SQLiteDemoActivity.java

package com.example.sqliteimagedemo;

import java.io.ByteArrayOutputStream;
import java.util.ArrayList;
import java.util.List;

import android.app.Activity;
import android.graphics.Bitmap;
import android.graphics.BitmapFactory;
import android.os.Bundle;
import android.util.Log;
import android.widget.ListView;

public class SQLiteDemoActivity extends Activity {
ArrayList<Contact> imageArry = new ArrayList<Contact>();
ContactImageAdapter adapter;

/** Called when the activity is first created. */
@Override
public void onCreate(Bundle savedInstanceState) {
super.onCreate(savedInstanceState);
setContentView(R.layout.main);


DataBaseHandler db = new DataBaseHandler(this);
// get image from drawable
Bitmap image = BitmapFactory.decodeResource(getResources(),
R.drawable.facebook);

// convert bitmap to byte
ByteArrayOutputStream stream = new ByteArrayOutputStream();
image.compress(Bitmap.CompressFormat.JPEG, 100, stream);
byte imageInByte[] = stream.toByteArray();
/**
* CRUD Operations
* */
// Inserting Contacts
Log.d("Insert: ", "Inserting ..");
db.addContact(new Contact("FaceBook", imageInByte));
// display main List view bcard and contact name

// Reading all contacts from database
List<Contact> contacts = db.getAllContacts();
for (Contact cn : contacts) {
String log = "ID:" + cn.getID() + " Name: " + cn.getName()
+ " ,Image: " + cn.getImage();

// Writing Contacts to log
Log.d("Result: ", log);
//add contacts data in arrayList
imageArry.add(cn);

}
adapter = new ContactImageAdapter(this, R.layout.screen_list,
imageArry);
ListView dataList = (ListView) findViewById(R.id.list);
dataList.setAdapter(adapter);
}
}


Contact.java
package com.example.sqliteimagedemo;

public class Contact {

 // private variables
 int _id;
 String _name;
 byte[] _image;

 // Empty constructor
 public Contact() {

 }

 // constructor
 public Contact(int keyId, String name, byte[] image) {
 this._id = keyId;
 this._name = name;
 this._image = image;

 }

 // constructor
 public Contact(String name, byte[] image) {
 this._name = name;
 this._image = image;
 }

 // getting ID
 public int getID() {
 return this._id;
 }

 // setting id
 public void setID(int keyId) {
 this._id = keyId;
 }

 // getting name
 public String getName() {
 return this._name;
 }

 // setting name
 public void setName(String name) {
 this._name = name;
 }

 // getting image
 public byte[] getImage() {
 return this._image;
 }

 // setting image
 public void setImage(byte[] image) {
 this._image = image;
 }
 }

ContactImageAdapter.java


package com.example.sqliteimagedemo;

import java.io.ByteArrayInputStream;
import java.util.ArrayList;

import android.app.Activity;
import android.content.Context;
import android.graphics.Bitmap;
import android.graphics.BitmapFactory;
import android.view.LayoutInflater;
import android.view.View;
import android.view.ViewGroup;
import android.widget.ArrayAdapter;
import android.widget.ImageView;
import android.widget.TextView;

public class ContactImageAdapter extends ArrayAdapter<Contact>{
Context context;
int layoutResourceId;
ArrayList<Contact> data=new ArrayList<Contact>();
public ContactImageAdapter(Context context, int layoutResourceId, ArrayList<Contact> data) {
super(context, layoutResourceId, data);
this.layoutResourceId = layoutResourceId;
this.context = context;
this.data = data;
}

@Override
public View getView(int position, View convertView, ViewGroup parent) {
View row = convertView;
ImageHolder holder = null;
if(row == null)
{
LayoutInflater inflater = ((Activity)context).getLayoutInflater();
row = inflater.inflate(layoutResourceId, parent, false);
holder = new ImageHolder();
holder.txtTitle = (TextView)row.findViewById(R.id.txtTitle);
holder.imgIcon = (ImageView)row.findViewById(R.id.imgIcon);
row.setTag(holder);
}
else
{
holder = (ImageHolder)row.getTag();
}
Contact picture = data.get(position);
holder.txtTitle.setText(picture ._name);
//convert byte to bitmap take from contact class
byte[] outImage=picture._image;
ByteArrayInputStream imageStream = new ByteArrayInputStream(outImage);
Bitmap theImage = BitmapFactory.decodeStream(imageStream);
holder.imgIcon.setImageBitmap(theImage);
return row;
}
static class ImageHolder
{
ImageView imgIcon;
TextView txtTitle;
}
}

main.xml

<?xml version="1.0" encoding="utf-8"?>
<LinearLayout xmlns:android="http://schemas.android.com/apk/res/android"
android:layout_width="fill_parent"
android:layout_height="fill_parent"
android:orientation="vertical" >
<ListView
android:id="@+id/list"
android:layout_width="fill_parent"
android:layout_height="0dp"
android:layout_weight="0.55" >
</ListView>
</LinearLayout>

screen_list.xml

<?xml version="1.0" encoding="utf-8"?>
<LinearLayout xmlns:android="http://schemas.android.com/apk/res/android"
android:layout_width="fill_parent"
android:layout_height="fill_parent"
android:orientation="horizontal"
android:padding="10dp" >
<ImageView
android:id="@+id/imgIcon"
android:layout_width="0dp"
android:layout_height="100dp"
android:layout_weight="0.71"
android:gravity="center_vertical" />
<TextView
android:id="@+id/txtTitle"
android:layout_width="80dp"
android:layout_height="fill_parent"
android:gravity="center_vertical"
android:textSize="14dp"
android:layout_marginLeft="7dp" />
</LinearLayout>

AndroidManifest.xml

<manifest xmlns:android="http://schemas.android.com/apk/res/android"
    package="com.example.sqliteimagedemo"
    android:versionCode="1"
    android:versionName="1.0" >

    <uses-sdk
        android:minSdkVersion="8"
        android:targetSdkVersion="15" />

    <application
        android:icon="@drawable/ic_launcher"
        android:label="@string/app_name"
        android:theme="@style/AppTheme" >
        <activity
            android:name=".SQLiteDemoActivity"
            android:label="@string/title_activity_main" >
            <intent-filter>
                <action android:name="android.intent.action.MAIN" />

                <category android:name="android.intent.category.LAUNCHER" />
            </intent-filter>
        </activity>
    </application>

</manifest>

Output will be like as below images:


Comments

  1. Sir, If we want to pass Url of image stored in drawble folder then how to do that? Reply asap

    ReplyDelete
    Replies
    1. Not possible. You will have to save image either to the SD CARD or the data/data/package folder. You can not write/save image in drawable/res. Sorry.

      Delete
  2. sir pls help asap. u only show 1 item how can i put multiple pics in the list
